Hardver IEEE 802.11n (draft) Wireless LAN specifikáció Egy 10/100 Mbps Ethernet LAN port 2 MB Flash memory / 16 MB SDRAM Levehető antenna (fordított SMA connector, female) Vezeték nélkül 7 működési mód: AP, AP Client, Workgroup Bridge, Workgroup Bridge hozzáférési ponttal, Repeater, WISP Client Router*, WISP Repeater* Wi-Fi Multimedia (WMM) Energiatakarékos ütemezési funkció Biztonság 64/128-bit WEP titkosítás WPA-PSK/WPA2-PSK WPA-EAP, WPA2-EAP TKIP, AES MAC cím szűrés SSID szélessáv letiltás funkció Minősített Wi-Fi Protected setup (WPS) Menedzsment D-Link Click’n Connect (DCC) telepítési varázsló Web alapú menedzsment

Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Signal Rate: Up to 300Mbps Frequency Range: 2.4-2.4835GHz Transmit Power: 20dBm(MAX) Wireless Modes: Range Extender, Router Wireless Security: Support 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES) Interface: 1x 10/100Mbps Ethernet port Buttons: WPS Range Extender mode: WPS/Default function Router mode: Normal Power/High Power/Default function LED Indicators: Signal Antenna: 2x internal antenna

Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Signal Rate: Up to 300Mbps Frequency Range: 2.4-2.4835GHz Transmit Power: 20dBm(MAX) Wireless Modes: Range Extender, Router Wireless Security: Support 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES) Interface: 1x 10/100Mbps Ethernet port Buttons: WPS Range Extender mode: WPS/Default function Router mode: Normal Power/High Power/Default function LED Indicators: Signal Antenna: 2x internal antenna

Interface: 1x 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1x 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough) 1x Grounding Terminal Antenna Type: Built-in 9dBi 2x2 Dual-polarized Directional Antenna Beam Width: 65° (H-Plane) / 35° (E-Plane) Note: For more details, please refer to datasheet Wireless Standards: IEEE 802.11b/g/n (with Pharos MAXtream disabled) Proprietary Protocol: TDMA Mode (with Pharos MAXtream enabled) Frequency: 2.4~2.483GHz

Interface: 1x 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1x 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough) Wireless Standards: IEEE 802.11a/n (with Pharos MAXtream disabled) Proprietary Protocol: TDMA Mode (with Pharos MAXtream enabled) Frequency: 5.15~5.85GHz

Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency: 2.4-2.4835GHz Interfaces: Fast Ethernet (RJ-45) Port *1(Support Passive PoE) Antenna Type: Internal 2* 3dBi Omni Mounting: Ceiling /Wall Mounting (Kits included)

HARDVER JELLEMZŐK Csatlakozások 1 db 10/100 Mb/s Ethernet port (RJ-45,Passzív PoE támogatott) Gomb Reset Hálózati tápegység 24VDC / 0.6A passzív PoE ellátás Energiafelvétel 6,3 W Méretek (Sz x Mé x Ma) 209 x 95 x 42,6 mm (8.2 × 3.7 × 1.7 in.) Antenna típusa 2 db 5 dBi külső omni, időjárásálló antenna Felszerelés Oszlop/Fali elhelyzés (szerelőkészlet a csomagban) Watch Dog Igen VEZETÉK NÉLKÜLI JELLEMZŐK Wi-Fi sztenderd IEEE 802.11n/g/b Frekvencia 2,4 GHz Adatátvitel 11n: max. 300 Mb/s (Dinamikus) 11g: max. 54 Mb/s (Dinamikus) 11b: max. 11 Mb/s (Dinamikus) Sugárzási teljesítmény CE:<20dBm FCC: <27dBm Vezeték nélküli funkciók Többszörös SSID (max. 8 SSID) Ki/Bekapcsolható Wi-Fi sugárzás Automatikus csatornakijelölés Sugárzás erősségének vezérlése (sugárzás igazítása dBm alapon) QoS(WMM) Load Balance Sebességkorlátozás Reboot ütemezés Vezeték nélküli ütemezés Vezeték nélküli statisztika SSID/AP/Kliens alapján Vezeték nélküli biztonság Engedélyező oldal Hozzáférés-vezérlés Vezeték nélküli Mac-cím szűrés Vezeték nélküli izoláció kliensek között SSID-VLAN Mapping Idegen behatolás megfigyelés 802.1X támogatott 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK

Interface: Fast Ethernet (RJ-45) Port *1(Support IEEE802.3af PoE) Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Antenna Type: Internal 2* 3dBi Omni Mounting: Ceiling /Wall Mounting (Kits included) Watch Dog: Yes Frequency: 2.4-2.4835GHz Wireless Functions: Multiple SSIDs (Up to 8 SSIDs), Enable/Disable Wireless Radio Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM), Rate Limit, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client Wireless Security: Captive Portal Authentication, Access Control, Wireless Mac Address Filtering Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK Auranet Controller Software: Yes Cluster Mode: Yes EAP Controller Software: Yes Email Alerts: Yes LED ON/OFF Control: Yes Management MAC Access Control: Yes SNMP: v1,v2c System Logging Local/Remote Syslog: Local/Remote Syslog Telnet: Yes Web-based Management: HTTP/HTTPS

Csatlakozások 1 db Gigabites Ethernet (RJ-45) port (támogatott az IEEE802.3af PoE) Gomb Reset Hálózati tápegység PoE vagy külső 12VDC / 1,5 A tápegység Energiafelvétel 12,7 W Méretek (Sz x Mé x Ma) 180 x 180 x 47,5 mm (7.1 x 7.1 x 1.9in.) Antenna típusa Belső Omni 2,4 GHz: 3 x 4dBi 5 GHz: 3 x 4dBi

Hálózati eszköz típus: access point Szabványok: IEEE 802.11g, IEEE 802.11b , IEEE 802.11n WLAN sebesség: 300 Mbps Titkosítás: WPA/WPA2/WPA-PSK/WPA2-PSK (AES/TKIP) MDI/MDIX Ethernet port Levehető RPSMA 4dBi antenna 2x to 3x eXtended Range Atheros chipset AP/Kliens/WDS mód Teljesítmény: 17dBm Frissíthető firmware

A TL-WA901ND Atheros chipsettel készül, támogatja a TP-Link extended range technológiáját. Az eszköz egy MDI/MDIX Ethernet portor és egy levehető RPSMA csatlakozós antennát is taltalmaz. Hálózati eszköz típus: access point Szabványok: IEEE 802.11g, IEEE 802.11b , IEEE 802.11n WLAN sebesség: 300 Mbps Titkosítás: WPA/WPA2/WPA-PSK/WPA2-PSK (AES/TKIP) Levehető RPSMA 4dBi antenna 2x to 3x eXtended Range Atheros chipset AP/Kliens/WDS mód Teljesítmény: 17dBm Frissíthető firmware

Device Interfaces 802.11n/g/b Wireless LAN 10/100 Fast Ethernet port Reset button WPS button LEDs Status/WPS 3 segment Wi-Fi signal strength indicator Standards IEEE 802.11n IEEE 802.11g IEEE 802.3u IEEE 802.11b Antennas Two external antennas Functionality Wireless Security Wi-Fi Protected Access (WPA/WPA2) WPS (PBC) Advanced Features D-Link One-Touch Extender Setup Device Management Supports QRS Mobile app for iPhone, iPad, iPod touch, and Android mobile devices Web UI Physical Dimensions 77 x 55.5 x 34 mm (3.03 x 2.28 x 1.33 inches)2 Weight 86.9 g Power Input: 110 to 240 V AC, 50/60 Hz

Wireless standard Wireless AC Frequency band mode Dual-band simultaneous Wireless speed 300 Mbps 2.4 GHz 867 Mbps 5 GHz Antenna type 2 fixed omni-directional antennas Wired interface 1 x Fast Ethernet LAN Wireless modes Wireless client Wireless extender

Eszköz interfészei 802.11ac/n/g/b/a Wireless LAN 10/100/1000 Gigabit Ethernet Port Reset gomb WPS gomb LED-ek státusz/ WPS jelzése 3 Szegmenses Wi-Fi Jelerősség indikátor Szabványok IEEE 802.11ac IEEE 802.11n IEEE 802.11g IEEE 802.11b IEEE 802.11a IEEE 802.3ab Antennák Két külső antenna Wireless Security Wi-Fi Protected Access (WPA/WPA2) WPS (PBC) Különleges jellemzők D-Link egygombos bővítő beállítása Eszközkezelő Támogatja a QRS alkalmazást iPhone, iPad, iPod touch és Android alapú mobileszközökön Web UI Fizikai jellemzők Méretek 120 x 59 x 42 mm (4.72 x 2.32 x 1.65 hüvelyk) Súly 139 g

Wireless Functions Wireless MAC Address Filtering Domain Login Function Transmit Power Control Antenna Type 3 external antennas Wireless Security WPA/WPA2, WPA-PSK/WPA2-PSK encryption Dimensions (W X D X H) 101 x 75 x 39 mm External Power Supply About 4.3W Signal Rate Up to 300Mbps Button Reset/WPS Button Wireless Standards IEEE 802.11n/g/b Frequency 2.4GHz Reception Sensitivity 11g 54M: -75dBm 11n HT20 MCS7: -73dBm 11n HT40 MCS7: -70dBm Package Contents 300Mbps Wi-Fi Range Extender MW300RE Quick Installation Guide

Standards and Protocols IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b Interface 1 * 10/100M Ethernet Port (RJ45) Button WPS Button, Reset Button Power Consumption 7.3W(max power consumption) Antenna 2* external Dimensions ( W x D x H ) 3.1*3.0*3.0 in. (80*78*77mm) WIRELESS FEATURES Frequency 2.4GHz & 5GHz(11ac) Signal Rate 5GHz:Up to 867Mbps 2.4GHz:Up to 300Mpbs Wireless Modes Range Extender/Access Point Concurrent Mode boost both 2.4G/5G Wi-Fi band Wireless Functions Wireless Statistic Concurrent Mode boost both 2.4G/5G Wi-Fi band Access Control LED Control Domain Login Function Wireless Security 64/128-bit WEP WPA-PSK / WPA2-PSK

Interface: 1x 10/100M Ethernet Port (RJ45) Button: RE (Range Extender) Button, Reset Button Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Antenna: 2x internal Power Consumption: About 3W Wireless Functions: WMM (Wi-Fi Multimedia) Wireless MAC Address Filtering Wireless Statistic Domain Login Function Wireless Security: 64/128/152-bit WEP WPA-PSK / WPA2-PSK

Interfaces: 1x 10/100M Ethernet Port (RJ45) Antenna: 2x external Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency: 2.4~2.4835GHz Wireless Modes: Range Extender, AP Mode Wireless Functions: Wireless MAC Address Filtering, Domain Login Function, Transmit Power Control Wireless Security: 64/128/152-bit WEP, WPA-PSK / WPA2-PSK

Standards and Protocols: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Interface: 1x 10/100Mbps Ethernet Port (RJ45) Button: RE (Range Extender) Button, Reset Button Antenna: 2x external Wireless Modes: Range Extender Wireless Functions: WMM (Wi-Fi Multimedia) Wireless MAC Address Filtering Wireless Statistic Domain Login Function Wireless Security: 64/128/152-bit WEP, WPA-PSK / WPA2-PSK

Network Standard: IEEE 802.11 b/g/n Interface: USB 2.0 Antenna: 2 x R SMA Antenna Operating Frequency: 2.4GHz Product Segment: N300 complete networking; 300Mbps Modulation: 64QAM, 16QAM, CCK, OFDM Security: 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPS support Dimensions: 55 x 90 x 11 mm (WxDxH)

Diagnostic LED Activity Security Wi-Fi Protected Access (WPA™ & WPA2™) Wi-Fi Protected Setup - PBC Standards IEEE 802.11ac Wave 2 IEEE 802.11n IEEE 802.11g IEEE 802.11b IEEE 802.11a Antenna Type Integrated antenna Requirements Operating System Windows 10/8.1/8/7/Vista/XP SP3 Interface Available USB Port Supports USB 3.0 standard Dimensions 97 x 19 x 12 mm (3.82 x 0.74 x 0.47 in) Weight 16.65 g

Dimensions (W X D X H) 1.69 × 0.68 × 0.33 in. (42.9 × 17.2 × 8.5 mm) Antenna Type Internal Signal Rate 11n: Up to 300Mbps(Dynamic) 11g: Up to 54Mbps(Dynamic) 11b: Up to 11Mbps(Dynamic) Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency 2.400 - 2.4835GHz Reception Sensitivity 270M: -62dBm@10% PER 130M: -65dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER Interfaces USB 2.0 Package Contents N300 Wireless Mini USB Adapter Quick installation guide Resource CD Transmission Power <20dBm Wireless Security WEP, WPA/WPA2, WPA-PSK/WPA2-PSK System Requirements Windows 10/8.1/8/7/XP (32/64bit)

Standards: IEEE 802.11b/g/n Signal Rate: Up to 150Mbps Frequency Range: 2.4-2.4835GHz Mode: Station, Access Point Wireless Security: Support 64/128-bit WEP, WPA-PSK/WPA2-PSK

Interfaces: USB 2.0 Antenna Type: Omni Directional Wireless Standards: IEEE 802.11ac/a/n/g/b Frequency: 5GHz, 2.4GHz Wireless Modes: Ad-Hoc / Infrastructure mode Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

Interface: USB 3.0 Antenna Type: Omni Directional Wireless Standards: IEEE 802.11ac/a/n/g/b Frequency: 5GHz, 2.4GHz Wireless Modes: Ad-Hoc / Infrastructure mode Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

150M sebességű USB wireless adapter kiterjesztett hatótávolsággal, kizárólag számítógépekbe. Alkalmas két vagy több notebook összekapcsolására és rádiós routeren keresztül internet ill. számítógépes hálózatra történő csatlakozásra. Hotspot hálózatokra történő csatlakozásra. Támogatott szabványok IEEE 802.11g, IEEE 802.11b, IEEE 802.11n Adatátvitel 150Mbps (802.11g/b/n) Frekvencia 2.4~2.4835 GHz WEP 128/64 bit Kimeneti teljesítmény 20 dBm USB USB 2.0 Hatótávolság beltéren 100 m Hatótávolság kültéren 300 m WPA igen WPA2 igen AES igen

Támogatott szabványok 802.11 g/b/n Adatátvitel 150 Mbps Frekvencia 2.4 GHz WEP igen Kimeneti teljesítmény 50-100 mW Antenna csatlakozó nincs AES igen WPA2 igen

IEEE 802.11n, 802.11g és 802.11b szabvány 150Mbps PCI Express csatlakozó QSS funkció titkosítás: 64/128/152-bit, WEP, WPA / WPA2/WPA-PSK/WPA2-PSK (TKIP / AES) roaming-technológia Ad-Hoc/Infrastructure módok

TP-Link SUPER AG technológia Extended Range technológia 2x-3x nagyobb hatótávolság Támogatott szabványok 802.11 g/b/n Adatátvitel 300 Mbps Frekvencia 2.4 GHz WEP igen Kimeneti teljesítmény 50-100 mW Antenna csatlakozó nincs AES igen WPA2 igen

Támogatott szabványok IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Adatátvitel 150Mbps (802.11n/g/b) Frekvencia 2.4~2.4835 GHz WEP 128/64 bit Kimeneti teljesítmény 20 dBm USB USB 2.0 Hatótávolság beltéren 100 m Hatótávolság kültéren 300 m WPA igen WPA2 igen AES igen

Támogatott szabványok 802.11 g/b/n Adatátvitel 300 Mbps Frekvencia 2.4 GHz WEP igen Kimeneti teljesítmény 50-100 mW Antenna csatlakozó nincs AES igen WPA2 igen

Interface: PCIe Antenna Type: Omni Directional, Detachable (RP-SMA) Antenna Gain: 2x2dBi Wireless Standards: IEEE 802.11n/g/b Frequency: 2.400-2.4835GHz Wireless Modes: Ad-Hoc / Infrastructure mode Wireless Security Support: 64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM

Szabványok: IEEE 802.11n IEEE 802.11g Vezeték nélküli frekvenciatartomány: 2.4 GHz to 2.4835 GHz Antennák: 2 Fix 5dBi külső antenna Biztonság: Wi-Fi Protected Access (WPA/WPA2) WPS™ (PBC/PIN) Szolgáltatások: mydlink™ app iOS és Android eszközökhöz Értesítések küldése: Vezeték nélküli behatolás/Online felhasználók bejelentkezése/Új firmware upgrade Felhasználói felügyelet: Access Control/Valós idejű böngészési napló UPnP™ támogatás: WDS Traffic Control T?zfal funkciók: Network Address Translation (NAT) Stateful Packet Inspection (SPI) MAC Address Filtering URL Filtering

Technical Specifications Device Interfaces IEEE 802.11 ac/n/g/b/a wireless LAN 10/100/1000 Gigabit Ethernet WAN port Four 10/100/1000 Gigabit Ethernet LAN ports LEDs Power Internet WLAN LAN (x4) WPS Antenna Type Four external antennas Operating Frequency 2.4 GHz band: 2400 - 2483.5 MHz 5 GHz band: 5150 - 5725 MHz Standards IEEE 802.11ac IEEE 802.11n IEEE 802.11g IEEE 802.3ab IEEE 802.11b IEEE 802.11a IEEE 802.3u Security WPA & WPA2 (Wi-Fi Protected Access) WPS (Wi-Fi Protected Setup) Advanced Features Web setup wizard QoS (Quality of Service) DMZ (Demilitarized Zone) Firewall - Network Address Translation (NAT) Guest zone IPv6 ready

Device Interfaces IEEE 802.11ac/n/g/b/a wireless LAN 10/100/1000 Gigabit Ethernet Internet WAN port Four 10/100/1000 Gigabit Ethernet LAN ports Antenna Type Three dual-band dipole external antennas Operating Frequency 2.4 GHz band: 2400 – 2497 MHz 5 GHz band: 5150 – 5250 and 5725 – 5850 MHz Standards IEEE 802.11ac IEEE 802.11n IEEE 802.11g IEEE 802.11b IEEE 802.11a IEEE 802.3u Security WPA & WPA2 (Wi-Fi Protected Access) WPS (Wi-Fi Protected Setup) Advanced Features Web setup wizard QoS (Quality of Service) DMZ (Demilitarized Zone) Firewall - Network Address Translation (NAT) Guest zone IPv6 ready Dimensions 189.95 x 149.75 x 38.11 mm Weight 302.6 grams Power Input: 100 to 240 V AC, 50/60 Hz Output: 12 V, 1.5 A

WiFi 300Mbps 802.11a/b/g/n Szimultán Dual-Band használat 4 belső antenna 4x 10/100 LAN 1x 10/100 WAN Cisco Connect SPI tűzfal WPA2 titkosítás SpeedBooster IPv6 támogatás

300Mbps vezeték nélküli router beépített antennák 4 LAN, 1 WAN port 802.11b/g/n MiMo Cisco Connect SPI tűzfal WEP, WPA2 titkosítások

802.11a/b/g/n és 802.11ac szabványok szimultán támogatása 4x belső antenna 1x gigabit WAN, 4x gigabit LAN port SPI tűzfal, WPA/WPA2 titkosítás 1x USB 3.0 port IPv6 támogatás DLNA

Sebesség: 1900Mbps Dual-Band Wireless-N600 + AC1300 802.11a/b/g/n és 802.11ac szabványok szimultán támogatása 6 belső antenna 1 gigabit WAN, 4 gigabit LAN portok SPI tűzfal, WPA/WPA2 titkosítás 1 USB 3.0 + 1 USB 2.0 port adattárolók részére IPv6 támogatás Vendég hozzáférés DLNA

Dimensions (W X D X H) 114x94x26 mm Protocols IPv4, IPv6 External Power Supply 5VDC/0.6A Antenna Type 2 x 5dBi fixed omni directional antennas Signal Rate 11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic) Button RESET Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency 2.4 - 2.4835GHz Reception Sensitivity 270M: -70dBm@10% PER 130M: -74dBm@10% PER 108M: -77dBm@10% PER 54M: -76dBm@10% PER 11M: -90dBm@8% PER 6M: -92dBm@10% PER 1M: -97dBm@8% PER Interfaces 2 10/100Mbps LAN ports 1 10/100Mbps WAN port Package Contents 300Mbps Wireless N Router Power adapter Quick Installation Guide Ethernet cable Transmission Power <20dBm Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK Wireless Functions WDS bridge WAN Type Dynamic IP/Static IP/PPPoE/L2TP/PPTP Management Parental Control Access control Local management Remote management DHCP Server Port Forwarding Virtual server, UPnP, DMZ Dynamic DNS DynDNS?NO-IP Firewall Security IP and MAC address binding Guest Network 2.4GHz guest network

Standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Signal Rate Up to 300Mbps Frequency Range 2.4-2.4835GHz Transmit Power 20dBm(MAX) Wireless Modes AP, Repeater, AP+WDS, WDS, Client, Multi-SSID Wireless Security 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES) SSID Broadcast Enable/Disable Wireless MAC Filtering Hardware Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX Interfaces 1 * 10/100Mbps Auto MDI/MDIX RJ45 WAN port 4 * 10/100Mbps Auto MDI/MDIX RJ45 LAN port Antennas 3* 5dBi Fixed Antenna Power Supply DC 9V/500mA (Output) Software WAN Type DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access, WISP Port Forwarding Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port QoS WMM, Bandwidth Control Access Control IP/MAC/Domain Filtering VPN Pass-through PPTP, L2TP, IPSec Others IPTV, Dynamic DNS, Static Routing, WOL, Backup & Restore, Firmware Upgrade Others Certification FCC, CE Environment Operating Temperature: 0?~40? Storage Temperature: -40?~70? Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing Package 1* WF2409E 1* 9V/500mA Power Adapter 1* Ethernet Cable 1* Quick Installation Guide (Multilingual)

Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Signal Rate: Up to 300Mbps Frequency Range: 2.4-2.4835GHz Transmit Power: 20dBm(MAX) Wireless Mode: AP, Repeater, AP+WDS, WDS, Client, Multi-SSID Wireless Security: 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES), SSID Broadcast Enable/Disable, Wireless MAC Filtering Standards: IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX Interface: 1x 10/100Mbps Auto MDI/MDIX RJ45 LAN port 4x 10/100Mbps Auto MDI/MDIX RJ45 LAN port LED: PWR, WLAN, LAN1-LAN4, WAN, WPS Button: WPS, Default Antenna: 2x 5dBi Fixed Antenna

Standards: IEEE 802.11b/g/n 2.4GHz, IEEE 802.11a/n/ac 5GHz, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3u 1000Base-TX Interface: 1x 10/100/1000M Auto MDI/MDIX RJ45 WAN port 4x 10/100/1000M Auto MDI/MDIX RJ45 LAN port Signal Rate: Up to 300Mbps2.4GHz, UP to 867Mbps 5GHz Frequency Range: 2.4-2.4835GHz; 5.180-5.825GHz Wireless Mode: AP, WDS, AP+WDS, Repeater, Client, Multiple AP Wireless Security: 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES), WPA/WPA2 SSID Broadcast Enable/Disable, Wireless MAC Filtering Antenna: 4x external 5dBi antenna, omni-directional

Interface: 4x 10/100/1000Mbps LAN Ports 1x 10/100/1000Mbps WAN Port 1x USB 2.0 Ports Antenna Type: 3 external antennas Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11n/g/b 2.4GHz Frequency: 5GHz and 2.4GHz Wireless Functions: Enable/Disable Wireless Radio, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption Quality of Service: WMM, Bandwidth Control WAN Type: Dynamic IP/Static IP/PPPoE/L2TP(Dual Access)/PPTP(Dual Access) Management: Access Control, Local Management, Remote Management DHCP: Server, Client, DHCP Client List, Address Reservation Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec Access Control: Parental Control, Local Management Control, Host List, Access, Schedule, Rule Management Firewall Security: DoS, SPI Firewall, MAC Address Filter, IP and MAC Address Binding Protocols: Supports IPv4 and IPv6 USB Sharing: Support Samba(Storage)/FTP Server/Media Server/Printer Server Guest Network: 2.4GHz guest network × 1, 5GHz guest network × 1 VPN Server: OpenVPN, PPTP VPN

Interfaces: 4x 10/100Mbps LAN ports 1x 10/100Mbps WAN port Antenna Type: Two dual band fixed antennas Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz Frequency: 2.4GHz and 5GHz Signal Rate: 5GHz: Up to 433Mbps, 2.4GHz: Up to 300Mbps Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption Quality of Service: WMM, Bandwidth Control Management: Access Control, Local Management, Remote Management Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, Comexe, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec Access Control: Parental Control, Local Management, Control, Host List, Access Schedule, Rule Management Firewall Security: DoS, SPI Firewall, IP Address Filtering/MAC Address Filtering/Domain Filtering, IP and MAC Address Binding Protocols: Supports IPv4 and IPv6 Guest Network: 2.4GHz guest network × 1, 5GHz guest network × 1

Interface: 4x 10/100/1000Mbps LAN Ports 1x 10/100/1000Mbps WAN Port USB 2.0 Ports Antenna Type: 3 * 5GHz 5dBi detachable antennas (RP-SMA), 3 * 2.4GHz internal antennas Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11n/g/b 2.4GHz Frequency: 5GHz and 2.4GHz Signal Rate: 5GHz: Up to 867Mbps, 2.4GHz: Up to 300Mbps Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption

Interfaces: 4x 10/100Mbps LAN Ports, 1x 10/100Mbps WAN Port, USB 2.0 Port Antenna Type: 2 Dual Band External Antennas Wireless Standards: IEEE 802.11n/g/b 2.4GHz, IEEE 802.11ac/n/a 5GHz Frequency: 2.4GHz and 5GHz Signal Rate: 2.4GHz: Up to 300Mbps, 5GHz: Up to 867Mbps Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption Quality of Service: WMM, Bandwidth Control WAN Type: Dynamic IP/Static IP/PPPoE/BigPond/ /L2TP(Dual Access) /PPTP(Dual Access) Management: Access Control, Local Management, Remote Management DHCP: Server, Client, DHCP Client List, Address Reservation Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, Comexe, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec Access Control: Parental Control, Local Management Control, Host List, Access, Schedule, Rule Management Firewall Security: DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding Protocols: Supports IPv4 and IPv6 USB Sharing: Support Samba(Storage)/FTP Server/Media Server/Printer Server Guest Network: 2.4GHz guest network × 1, 5GHz guest network × 1

Interface: 4x 10/100Mbps LAN Ports 1x 10/100Mbps WAN Port Antenna: 3x 2.4GHz Antennas, 2x 5GHz Antennas Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz Wireless Speeds: 450Mbps(2.4GHz), 867Mbps(5GHz) Frequency: 2.4-2.5GHz, 5.15-5.25GHz Wireless Modes: Wireless Router, WDS(Four Address), WDS(AP+APC) Wireless Security: WEP, WPAWPA2, WPA-PSKWPA2-PSK Quality of Service: WMM, Bandwidth Control WAN Type: Dynamic IP/Static IP/PPPoE/BigPond/ /L2TP(Dual Access) /PPTP(Dual Access) Management: Access Control, Local Management, Remote Management DHCP: Server, Client, DHCP Client List, Address Reservation VPN Pass-Through: PPTP, L2TP, IPSec Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management Protocols: IPv4, IPv6 Guest Network: 2.4GHz guest network, 5GHz guest network

Interface: 4x 10/100/1000Mbps LAN Ports 1x 10/100/1000Mbps WAN Port USB 2.0 Ports Antenna Type: Three 5GHz 5dBi detachable antennas (RP-SMA) Three 2.4GHz internal antennas Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz Frequency: 2.4GHz and 5GHz Signal Rate: 5GHz: Up to 1300Mbps, 2.4GHz: Up to 450Mbps Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)/BigPond DHCP: Server, Client, DHCP Client List, Address Reservation Quality of Service: WMM, Bandwidth Control Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, Comexe, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management Firewall Security: DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding Protocols Supports: IPv4 and IPv6 USB Sharing: Support Samba(Storage)/FTP Server/Media Server/Printer Server Management: Access Control, Local Management, Remote Management Guest Network: 2.4GHz guest network × 1, 5GHz guest network × 1

HARDVER JELLEMZŐK Csatlakozások: 4 db 10/100/1000 Mb/s LAN csatlakozó 1 db 10/100/1000 Mb/s WAN csatlakozó 1 db USB 3.0 Port + 1 db USB 2.0 port Gomb WPS/Reset Gomb Wi-Fi Ki/Be Gomb Ki/Bekapcsoló Gomb Antenna: 3 db dual bandes cserélhető antenna Külső tápellátás: 12V/3.3A Méretek (Sz x Mé x Ma): 221 X 86 X 168,5mm (8.7 X 3.4 X 6.6 in.) VEZETÉK NÉLKÜLI JELLEMZŐK Wi-Fi: IEEE 802.11ac/n/a 5GHz IEEE 802.11b/g/n 2,4GHz Frekvencia: 2,4 GHz és 5 GHz Adatátvitel: 5GHz: max. 1300 Mb/s 2,4GHz: max. 600 Mb/s Vezeték nélküli funkciók: Bekapcsolható/Kikapcsolható Vezeték nélküli sugárzás, WDS Bridge, WMM, Vezeték nélküli statisztika Vezeték nélküli biztonság: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 titkosítás SZOFTVER JELLEMZŐK QoS (szolgáltatás minősége): WMM, Sávszélesség szabályozás WAN típus: Dynamic IP/Static IP/PPPoE/ Vezérlés: Hozzáférés-szabályozás Helyi vezérlés Távoli vezérlés DHCP: Szerver, kliens, DHCP kliens lista, Címfoglalás Port Forwarding:Virtuális szerver, Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, Comexe, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec Hozzáférés kezelése Szülői felügyelet, Helyi Vezérlés, Hozzáférés Ütemezés, Host Lista, Szabályok Létrehozása Tűzfal biztonság DoS, SPI Firewall IP Cím szűrés/MAC Cím szűrés/Domain szűrés IP- és MAC-cím összekapcsolás Protokollok: Támogatja az IPv4 és IPv6 protokollt USB megosztás: Támogatja a Samba(Storage)/FTP /Media /Nyomtató Szervert Vendéghálózat: 1 db vendéghálózat 2,4GHz-en 1 db vendéghálózat 5GHz-en

Interfaces: 3x 10/100Mbps LAN Ports, 1x 10/100Mbps LAN/WAN Port, 1x SIM Card Slot Antenna: 3x Internal Wi-Fi Antennas, 2x Detachable External 4G LTE Antennas Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz Frequency: 2.4GHz and 5GHz Signal Rate: 300Mbps at 2.4GHz, 433Mbps at 5GHz Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions Network Type: 4G: FDD-LTE Cat4 (800/900/1800/2100/2600MHz) TDD-LTE (2300/2600MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS (900/2100MHz) 2G: EDGE/GPRS/GSM (850/900/1800/1900MHz)

Network Type: FDD-LTE Cat4 (800/900/1800/2100/2600MHz) DC-HSPA+/HSPA/UMTS (900/2100MHz) EDGE/GPRS/GSM (850/900/1800/1900MHz) Interface: 1 micro USB port for power supply SIM card slot Micro SD card slot Antenna: Internal Antenna Dimensions ( W x D x H ): 4.2 × 2.6 × 0.6 in. (106 × 66 × 16mm) Power Supply : Internal 2550mAh Rechargeable Battery Micro SD Card Reader: Up to 32GB Wireless Standards: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Frequency: 2.4GHz & 5GHz Wireless Security: Support WPA-PSK/WPA2-PSK,Wireless MAC Filtering, Enable/Disable SSID Broadcast DHCP: DHCP server, DHCP Client List

Interface: 1x 10/100Mbps WAN/LAN Port USB 2.0 Port for 3G/4G modem mini USB Port for power supply Antenna Type: Internal Antenna Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency: 2.4-2.4835GHz Wireless Modes: 3G Router, Travel Router (AP), WISP Client Router Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, Wireless MAC Filtering DHCP: Server, DHCP Client List, Address Reservation Port Forwarding: Virtual Server, Port Triggering, DMZ, UPnP Access Control: Parental Control, Host List, Access Schedule, Rule Management Security: Firewall, MAC filtering, Denial of Service (DoS)

Standards: IEEE 802.11n/g/b, IEEE 802.3/3u, USB 2.0 Interface: USB 2.0 Port for LTE/HSPA+/HSUPA/HSDPA/UMTS/EVDO USB Modem 1 10/100Mbps WAN Port 4 10/100Mbps LAN Ports support the auto-Negotiation and auto-MDI/MDIX Antenna: 3dBi Omni Directional Antenna X 2

Interface: 3x 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1x SIM Card Slot Antenna Type: 2x Internal Wi-Fi Antennas, 4G LTE Antennas Wireless Standards: IEEE 802.11b/g/n Frequency: 2.4GHz Signal Rate: 300Mbps Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions Network Type: 4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz) TDD-LTE B38/B40 (2600/2300MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz) 2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz) Quality of Service: Traffic Control(IP QoS) Operating Modes: 3G/4G Router, Wireless Router Management: Access Control, Local Management, Remote Management WAN Connection Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) DHCP: Server, Client, DHCP Client List, Address Reservation Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management Firewall Security: DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding Protocols: Supports IPv4 and IPv6 Guest Network: 2.4GHz guest network x 1

Interface: 1x 10/100Mbps WAN/LAN Port, 1x Micro USB Port Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Dimensions ( W x D x H ): 57 x 57 x18 mm Antenna Type: On-Board Frequency: 2.4-2.4835GHz Signal Rate: 11n: Up to 300Mbps(dynamic), 11g: Up to 54Mbps(dynamic), 11b: Up to 11Mbps(dynamic) Wireless Modes: Router Mode, Repeater Mode, Client Mode, AP Mode, WISP Router Mode Wireless Functions: Enable/Disable Wireless Radio, WMM, Wireless Statistics Wireless Security: 64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Interface: 4x 10/100Mbps LAN PORTS 1x 10/100Mbps WAN PORT Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Antenna: 2 Internal Antennas Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128-bit WEP, WPA / WPA2,WPA-PSK / WPA2-PSK WAN Type: Dynamic IP/Static IP/PPPoE/PPTP/L2TP DHCP: Server, Client, DHCP Client List, Address Reservation Quality of Service: WMM, Bandwidth Control Port Forwarding: Virtual Server,Port Triggering, UPnP, DMZ Dynamic DNS: DynDns, Comexe, NO-IP VPN Pass-Through: PPTP, L2TP, IPSec (ESP Head) Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management Firewall Security: DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding Management: Access Control, Local Management, Remote Management

Interface: 4x 10/100Mbps LAN PORTS 1x 10/100Mbps WAN PORT Antenna: 3*5dBi Fixed Omni Directional Antenna Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency: 2.4-2.4835GHz Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security: 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
